Specifications
-
Product specifications for Deep 1 / No Dim / 2700K
BRAND

Arkoslight

TYPE

Ceiling

MATERIAL

Aluminium,

Polymethyl Methacrylate

DIMENSIONS

Ø 9 cm x 7.3 cm x 22 cm

LIGHT TEMPERATURE

2700K; 3000K or 4000K

ELECTRICAL CHARACTERISTICS

(1) 10,5W (No Dim; Push; Dali) 350 mA
(2) 15,5W (No Dim; Push; Dali) 500 mA
(3) 22W (No Dim; Push; Dali) 700 mA
(4) 27W(No Dim; Push; Dali) 700 mA

PHOTOMETRIC DATA

LED L80B10 >60.000h
2800 lm or 2100 lm (2700K)
4050 lm or 2275 lm (3000K)
3075 lm; 1675 lm or 2300 lm (4000K)
CRI>90
Energy efficiency class D or E
IP43 / IP54

Arkoslight

Deep

Deep - Deep

Deep is a family of LED downlights for general lighting functions that stands out for its attractive appearance, where the diffuser is distinctly recessed in relation to the level of the perimeter frame. With its different sizes, it adapts to each project’s requirements and adds a differentiating attribute.

Model: Deep
Mini
Deep
Maxi
Version
Dimming Control
Light Temperature
Specifications
-
Product specifications for Deep 1 / No Dim / 2700K
BRAND

Arkoslight

TYPE

Ceiling

MATERIAL

Aluminium,

Polymethyl Methacrylate

DIMENSIONS

Ø 9 cm x 7.3 cm x 22 cm

LIGHT TEMPERATURE

2700K; 3000K or 4000K

ELECTRICAL CHARACTERISTICS

(1) 10,5W (No Dim; Push; Dali) 350 mA
(2) 15,5W (No Dim; Push; Dali) 500 mA
(3) 22W (No Dim; Push; Dali) 700 mA
(4) 27W(No Dim; Push; Dali) 700 mA

PHOTOMETRIC DATA

LED L80B10 >60.000h
2800 lm or 2100 lm (2700K)
4050 lm or 2275 lm (3000K)
3075 lm; 1675 lm or 2300 lm (4000K)
CRI>90
Energy efficiency class D or E
IP43 / IP54
